Pro-Face Pfxge4401Wad Hmi Superior Quality

Description

PRO-FACE PFXGE4401WAD HMI SUPERIOR QUALITY PRODUCT WOLDWIDE FREE SHIPPING

Display specifications

Display type

TFT Color LCD

Display size

7.0″

Resolution

800 x 480 pixels (WVGA)

Effective display area

W154.08 x H85.92 mm [W6.066 x H3.382 in.]

Display colors

65,536 colors

Backlight

LED

Backlight service life

20,000 hrs. or more (each in continuous operation at 25 °C [77 °F] before backlight brightness decreases to 50%)

Brightness control

8 Levels (Adjusted with software)

Touch panel type

Resistive Film (analog)

Touch panel lifetime

1,000,000 times or more, Sweeping 100,000 times or more

Language fonts

Chinese (Simplified)

Character sizes

Standard font: 8 x 8, 8 x 16, 16 x 16 and 32 x 32 pixel fonts

Font sizes

Width can be expanded 1 to 8 times. Height can be expanded 1/2 and 1 to 8 times.

8 x 8 dots

40 char. x 30 rows

8 x 16 dots

40 char. x 15 rows

16 x 16 dots

20 char. x 15 rows

32 x 32 dots

10 char. x 7 rows

Electrical specifications

Rated input voltage

24 Vdc

Allowable voltage drop

1 ms or less with lowest input voltage, 10 ms or less with rated input voltage

Power consumption

8.2W

In-rush current

50 A or less

Voltage endurance

600 Vac, 20 mA for 1 minute

Insulation resistance

500 Vdc, 10 MΩ or more (between power terminal and FG terminals)

Environmental specifications

International safety standards

Surrounding air temperature

0 to 50 °C [32 to 122 °F]

Storage temperature

-20 to +60 °C [-4 to 140 °F]

Ambient humidity

85 % RH (Wet bulb temperature: 39 °C [102.2 °F] max. – no condensation)

Storage humidity

10% to 90% RH (Non condensing, wet bulb temperature 39 °C [102.2 °F] or less)

Dust

0.1 mg/m3 (10-7 oz/ft3) or less (non-conductive levels)

Pollution degree

For use in Pollution Degree 2 environment

Corrosive gases

Free of corrosive gases

Air pressure (altitude range)

2,000 m [6,561 ft.] max.

Vibration resistance

IEC/EN60068-2-6, 5 to 150 Hz, 3.5 mm (0.38 in) max., 1gn pm 3 axes

Concussion resistance

IEC 60068-2-27, 1/2 sinusoidal pulse for 11 ms, 15g on 3 axes

Electrostatic discharge immunity

EN/IEC 61131-2, 4 kV direct contact, 8 kV air contact

Electromagnetic compatibility (EMC)

IEC 61000 – 4 – 5, 0.5 kV (Differential Mode on power supply), 1 kV (Common Mode on power supply)

Memory

Application memory

FLASH EPROM 8 MB

Backup memory

FLASH EPROM 128 KB

Clock accuracy

Variations in operating conditions and battery life can cause a clock inaccuracy from -380 to +90 seconds per month.

Interface specifications

Serial (COM1)

Asynchronous Transmission: RS-232C, Data Length: 7 or 8 bits, Stop Bit: 1 or 2 bits, Parity: None, Even or Odd, Data Transmission Speed: 2,400 to 115,200 bps, Connector: D-Sub 9 (plug)

Serial (COM2)

Asynchronous Transmission: RS-422 / 485, Data Length: 7 or 8 bits, Stop Bit: 1 or 2 bits, Parity: None, Even or Odd, Data Transmission Speed: 2,400 to 187,500 bps, Connector: D-Sub 9 pin (plug)

USB (Type A)

Conforms to USB 2.0 (Type A) x 1
Communication distance: 5 m [16.4 ft.] or less

USB (mini-B)

Conforms to USB (mini-B) x 1, Used in Project file upload/download

Structural specifications

Grounding

Functional grounding: Grounding resistance of 0.1 Ω, 2mm2 (AWG 14).

Cooling method

Natural air circulation

Structure

Front Panel: IP65 (IEC60529), Enclosure type 4 indoor use only (UL 50) with screw installation fasteners, Rear Panel: IP20 (IEC 60529)

External dimensions

W207.8 x H153.2 x D59.8 mm [W8.18 x H6.03 x D2.35 in.]
