Schneider Tm2Ami8Ht Plc Superior Quality Product

SCHNEIDER TM2AMI8HT PLC SUPERIOR QUALITY PRODUCT SHIPPING WORLDWIDE

Range of product	Modicon M238 logic controller
Product or component type	I/O expansion module
analogue input number	8
Analogue input type	Current 4…20 mA non differential voltage 0…10 V non differential

Range compatibility	Twido Advantys OTB
Analogue input resolution	10 bits
LSB value	19.5 µA current 9.7 mV voltage
Permissible continuous overload	40 mA, analogue input type: current 13 V, analogue input type: voltage
Input impedance	>= 10 kOhm voltage 470 Ohm current
Sampling duration	160 ms
Acquisition period	160 ms per channel + 1 controller cycle time
Measurement error	+/- 0.2 % of full scale at 25 °C
Temperature coefficient	+/-0.01 %FS/°C
Repeat accuracy	+/- 0.4 %FS
Non-linearity	+/- 0.002 %FS
Total error	+/-1 %FS
Type of cable	Shielded cable
Insulation between channel and internal logic	Photocoupler
supply	External supply
[Us] rated supply voltage	24 V DC
Supply voltage limits	20.4…28.8 V
Electrical connection	1 removable screw terminal block power supply 1 removable screw terminal block sensors
Current consumption	45 mA at 24 V DC external 60 mA at 5 V DC internal

Shipping Info

Order by 2PM to get delivered next working day! We use 24 hours service with carriers in most cases so that you can get your order delivered on time.

There is £4.99 charge for delivery under £50 Orders. Additional charges will be imposed by our couriers for delivery to remote area, a surcharge may be levied to cover carriage to these areas.

Reviews (0)

Reviews

There are no reviews yet.

Be the first to review “Schneider Tm2Ami8Ht Plc Superior Quality Product”

Schneider Tm2Ami8Ht Plc Superior Quality Product

₹ 16,385.00

Estimated delivery:3 days

Description

SCHNEIDER TM2AMI8HT PLC SUPERIOR QUALITY PRODUCT SHIPPING WORLDWIDE

Range of product	Modicon M238 logic controller
Product or component type	I/O expansion module
analogue input number	8
Analogue input type	Current 4…20 mA non differential voltage 0…10 V non differential

Range compatibility	Twido Advantys OTB
Analogue input resolution	10 bits
LSB value	19.5 µA current 9.7 mV voltage
Permissible continuous overload	40 mA, analogue input type: current 13 V, analogue input type: voltage
Input impedance	>= 10 kOhm voltage 470 Ohm current
Sampling duration	160 ms
Acquisition period	160 ms per channel + 1 controller cycle time
Measurement error	+/- 0.2 % of full scale at 25 °C
Temperature coefficient	+/-0.01 %FS/°C
Repeat accuracy	+/- 0.4 %FS
Non-linearity	+/- 0.002 %FS
Total error	+/-1 %FS
Type of cable	Shielded cable
Insulation between channel and internal logic	Photocoupler
supply	External supply
[Us] rated supply voltage	24 V DC
Supply voltage limits	20.4…28.8 V
Electrical connection	1 removable screw terminal block power supply 1 removable screw terminal block sensors
Current consumption	45 mA at 24 V DC external 60 mA at 5 V DC internal
